Smart Switch Board
​
Why stick to regular switchboards?
The best smart switchboards which are unique in design, elegant in look and intelligent in performance. They add aesthetic appeal, efficiency & luxury with our sleek toughened glass switchboards.
Our SSBs are more than just a product and are one of a kind
-
Easy installation with no extra wiring
-
Fits best for existing and new homes
-
Experience an advanced lifestyle with our smart switches
Our Modules
​
Technical specifications:
-
Dimensions: 220 X 160 X 50 in mm
-
Consists of 8 switches, 1 Fan regulator
-
3 pin Plug Socket (Provision is for 3)
-
Two switches: 16 A – 1500 W
-
Power source: 110 V – 270 V AC, 50 Hz
-
Load on Switches (7A): 600 W, LED Bulb < 100 W
-
Load on Switches (16 A): 1500 W
-
Load on Fan point: 250 W per each Fan
-
RF Module Security: 128-bit AES Encryption
-
Operating temperature: 5°C to 55°C
-
Energy consumption of SSB: 0.046 to 0.083 kWh per day
Best for Halls, Bedroom, Living Room, Dining Room, Hotels, Restaurants & Commercial units
​
8 Module
Technical specifications:
-
Dimensions: 240 x 100 x 40 in mm
-
Consists of 5 switches, 1 Fan regulator
-
3 pin Plug Socket (Provision is for one)
-
Two switches: 16 A – 1500 W
-
Power source: 110 V – 270V AC, 50 Hz
-
Load on Switches (7 A): 600W per each 7 A switch
-
Load on Switches (16 A): 1500 W per 16 A switch
-
Load on Fan point: 250 W per each Fan
-
RF Module Security: 128-bit AES Encryption
-
Operating temperature: 5°C to 55°C
-
Energy consumption of SSB: 0.046 to 0.083 kWh per day
Best for Hall, Master Bedroom, Guest Room, Hospitals, Hotels & TV point
​
​
4 Module
Technical specifications:
-
Dimensions: 150 X 95 X 36 in mm
-
Consists of: 4 switches
-
1 switch: 16 A and other three switches are 7Amps.
-
Power source: 110 V – 270 V AC, 50 Hz
-
Load on Switches (7 A): 600 W per each 7 A switch
-
Load on Switches (16 A): 1500 W per 16A switch
-
Resistive Load: < 1500 W, LED Load< 100W
-
Operating temperature: 5°C to 55°C
-
Energy consumption of SSB: 0.046 to 0.083 kWh per day
Best for lavish Bathing, Washroom, Passageway, Balcony, Terrace, Kitchen
​
​
2 Module
Technical specifications:
-
Dimensions: 100 X 95 X 35 in mm
-
Consists of: 2 switches
-
All switches: 16 A – 1500 W
-
Power source: 110 V – 270 V AC
-
Resistive Load: < 1500 W, LED Load< 100 W
-
Operating temperature: 5°C to 55°C
-
Energy consumption of SSB: 0.046 to 0.083 kWh per day
Best for Dining, Washroom, Passageway, Balcony, Terrace, Kitchen, Hospitals & Hotels
